Extreme Networks 220-12p-10GE2端口交换机 PDF资料
1.产 品 资 料 介 绍：
Extreme Networks 220-12p-10GE2 网络交换机
一、产品概述
Extreme Networks 220-12p-10GE2 属于 ExtremeSwitching 220 系列，这是一款面向中小型企业、分支机构和园区网络的高性能 千兆 PoE+ 管理型交换机，提供灵活的 10G 上行端口，兼具高性价比与企业级特性，适用于接入层与边缘网络部署。
二、主要技术参数
端口配置：
12 个 10/100/1000BASE-T RJ-45 端口（均支持 PoE+ 供电）
2 个 10G SFP+ 光纤上行端口
PoE 总功率预算：约 185W
交换容量（Switching Capacity）：56 Gbps
包转发率（Forwarding Rate）：41.6 Mpps
MAC 地址表容量：8K
VLAN 数量：最高支持 256 个 VLAN
管理方式：
Web 图形化界面
命令行（CLI）
SNMP v1/v2c/v3
云端 ExtremeCloud 管理
机箱规格：
1U 机架式设计
尺寸约：高 44 mm × 宽 441 mm × 深 254 mm
重量约 3.5 kg
散热方式：智能风扇控制（低噪音设计）
三、产品特点
高性能 10G 上行
提供两个 10G SFP+ 上行端口，支持与核心或汇聚交换机的高速连接，满足未来带宽增长需求。PoE+ 全端口供电能力
12 个千兆端口全部支持 IEEE 802.3af/at PoE+ 标准，可为 AP、IP 摄像机、VoIP 电话等设备直接供电。灵活管理与配置
支持 Web 管理、命令行 CLI、SNMP 及 ExtremeCloud 云端集中控制，适应不同层级网络管理员需求。丰富的二层功能
支持 VLAN、端口聚合（LACP）、生成树（STP/RSTP/MSTP）、端口镜像、QoS 流量优先级控制及访问控制列表（ACL）。静态三层路由能力
除了二层功能外，还支持静态路由，可实现简单的网络分段与流量隔离。节能静音设计
智能温控风扇可根据负载自动调整转速，兼顾散热与噪音控制，适合部署于办公环境。
Extreme Networks 220-12p-10GE2端口交换机 英文介绍
Extreme Networks 220-12p-10GE2 Network Switch
1、 Product Overview
Extreme Networks 220-12p-10GE2 belongs to the ExtremeSwitching 220 series, which is a high-performance Gigabit PoE+managed switch designed for small and medium-sized enterprises, branch offices, and campus networks. It provides flexible 10G upstream ports, combines high cost-effectiveness with enterprise level features, and is suitable for deployment in both access layer and edge networks.
2、 Main technical parameters
Port configuration:
12 10/100/1000BASE-T RJ-45 ports (all supporting PoE+power supply)
2 10G SFP+fiber optic uplink ports
PoE total power budget: approximately 185W
Switching Capacity: 56 Gbps
Forwarding Rate: 41.6 Mpps
MAC address table capacity: 8K
Number of VLANs: Supports up to 256 VLANs
Management method:
Web graphical interface
Command Line (CLI)
SNMP v1/v2c/v3
Extreme Cloud Management in the Cloud
Chassis specifications:
1U rack mounted design
Dimensions: Approximately 44mm in height, 441mm in width, and 254mm in depth
Weight approximately 3.5 kg
Cooling method: Intelligent fan control (low-noise design)
3、 Product Features
High performance 10G uplink
Provide two 10G SFP+upstream ports to support high-speed connections with cores or aggregation switches, meeting future bandwidth growth needs.
PoE+full port power supply capability
All 12 gigabit ports support the IEEE 802.3af/at PoE+standard and can directly power devices such as APs, IP cameras, and VoIP phones.
Flexible management and configuration
Support web management, command-line CLI, SNMP, and ExtremeCloud cloud centralized control to meet the needs of network administrators at different levels.
Rich second layer functions
Supports VLAN, Port Aggregation (LACP), Spanning Tree (STP/RSTP/MSTP), Port Mirroring, QoS Traffic Priority Control, and Access Control List (ACL).
Static three-layer routing capability
In addition to layer 2 functionality, it also supports static routing, enabling simple network segmentation and traffic isolation.
Energy saving and silent design
The intelligent temperature controlled fan can automatically adjust its speed according to the load, balancing heat dissipation and noise control, making it suitable for deployment in office environments.
Extreme Networks 210-24p-GE2网络交换机 产品展示
