Rexroth VT-HNC100-1-23W-08-S-0 数字轴控制器 PDF资料
1.产 品 资 料 介 绍：
产品定位
属于 Rexroth VT‑HNC100 系列数字轴控制器，用于高端运动控制、机床自动化或液压轴控制系统。
适用于单轴或多轴闭环控制系统，提供高精度位置控制。
主要特点
高精度轴控制：
支持数字位置传感器输入（如增量编码器或 SSI），实现精确轴位置反馈和运动控制。丰富的输入/输出接口：
提供数字量 I/O，可用于连接开关、传感器和执行器，实现完整的轴控制功能。模块化设计：
可安装于机柜或面板中，支持快速维护和系统扩展。工业级可靠性：
工作温度范围：0 ℃ 至 +50 ℃
存储温度范围：‑20 ℃ 至 +70 ℃
抗振动、抗干扰设计，适合工业环境。
供电与尺寸：
电压范围：约 18 VDC 至 36 VDC
尺寸参考（单轴版本）：约 71 × 155 × 204 mm（宽 × 高 × 深）
通信接口：
支持 RS232 或可选 PROFIBUS‑DP 等工业通信接口，用于上位控制系统连接。
典型应用场景
精密机床与加工中心的轴控制系统
液压或电机轴闭环控制
多轴同步控制的工业自动化设备
高可靠性、高精度运动控制场合
Rexroth VT-HNC100-1-23W-08-S-0 数字轴控制器 英文介绍
Product positioning
Belonging to the Rexroth VT-HNC100 series digital axis controller, it is used for high-end motion control, machine tool automation, or hydraulic axis control systems.
Suitable for single axis or multi axis closed-loop control systems, providing high-precision position control.
Main Features
High precision axis control:
Support digital position sensor input (such as incremental encoder or SSI) to achieve precise axis position feedback and motion control.
Rich input/output interfaces:
Provide digital I/O, which can be used to connect switches, sensors, and actuators to achieve complete axis control functions.
Modular design:
Can be installed in cabinets or panels, supporting quick maintenance and system expansion.
Industrial grade reliability:
Working temperature range: 0 ℃ to+50 ℃
Storage temperature range: -20 ° C to+70 ° C
Anti vibration and anti-interference design, suitable for industrial environments.
Power supply and size:
Voltage range: approximately 18 VDC to 36 VDC
Size reference (single axis version): approximately 71 × 155 × 204 mm (width × height × depth)
Communication interface:
Supports industrial communication interfaces such as RS232 or optional PROFIBUS-DP for connecting to upper control systems.
Typical application scenarios
Axis control system for precision machine tools and machining centers
Hydraulic or motor shaft closed-loop control
Industrial automation equipment with multi axis synchronous control
High reliability and high-precision motion control applications
Rexroth VT-HNC100-1-23W-08-S-0 数字轴控制器 产品展示
