TRICONEX 3700A分析模块 PDF资料
1.产 品 资 料 介 绍：
TRICONEX 3700A 分析模块 产品特点
产品概述：
TRICONEX 3700A 分析模块是 Tricon 安全控制系统（Tricon Safety System）中的关键模块之一，用于监测、采集和分析工业过程中的模拟和数字信号，为主处理器提供可靠的实时数据。数据采集能力：
支持多路模拟输入（AI）和数字输入（DI）信号采集。
可对温度、压力、流量、电压、电流等多种工艺参数进行实时监测。
高精度数据采集，保证系统控制和安全逻辑的准确性。
分析与处理功能：
对采集的信号进行实时分析、滤波和异常检测。
可生成报警信号，供系统逻辑决策使用。
支持多种信号类型的线性化与转换，便于系统集成。
三模冗余架构 (TMR)：
模块设计符合 Triconex TMR 架构标准，提高系统容错能力和安全性。
即使单通道或单模块出现故障，系统仍能正常运行，保证安全和可靠性。
诊断与自检功能：
内置自检和健康监测功能，能够实时检测模块及通道状态。
故障时可自动隔离异常通道，向主处理器发出报警，确保系统连续可靠运行。
环境适应性：
工业级设计，耐高温、抗电磁干扰、防震动、防尘，适用于复杂工况环境。
安装与集成：
模块化设计，可直接插入 Triconex 系统机架。
可与 3008 主处理器、3625/3664 I/O 模块及 HMI 操作面板无缝协作，实现数据采集与控制。
安全与应用场景：
符合 IEC 61508 SIL3 安全标准，适合关键安全控制系统使用。
广泛应用于石油化工、炼油厂、天然气平台、电力及海上平台等工业安全系统。
用于紧急停机 (ESD)、过程联锁、关键设备监控和工艺优化控制。
TRICONEX 3700A分析模块 英文介绍
TRICONEX 3700A Analysis Module Product Features
Product Overview:
The TRICONEX 3700A analysis module is one of the key modules in the Tricon Safety System, used for monitoring, collecting, and analyzing analog and digital signals in industrial processes, providing reliable real-time data for the main processor.
Data collection capability:
Support multi-channel analog input (AI) and digital input (DI) signal acquisition.
Real time monitoring of various process parameters such as temperature, pressure, flow rate, voltage, and current.
High precision data collection ensures the accuracy of system control and safety logic.
Analysis and processing functions:
Real time analysis, filtering, and anomaly detection of collected signals.
Can generate alarm signals for system logic decision-making.
Support linearization and conversion of multiple signal types, facilitating system integration.
The third mock examination redundant architecture (TMR):
The module design complies with the Triconex TMR architecture standard, improving the system's fault tolerance and security.
Even if a single channel or module fails, the system can still operate normally, ensuring safety and reliability.
Diagnostic and self checking functions:
Built in self checking and health monitoring functions, capable of real-time detection of module and channel status.
When a fault occurs, the abnormal channel can be automatically isolated and an alarm can be sent to the main processor to ensure the continuous and reliable operation of the system.
Environmental adaptability:
Industrial grade design, resistant to high temperatures, electromagnetic interference, vibration, and dust, suitable for complex working environments.
Installation and integration:
Modular design, can be directly inserted into the Triconex system rack.
It can seamlessly collaborate with the 3008 main processor, 3625/3664 I/O modules, and HMI operation panel to achieve data acquisition and control.
Security and application scenarios:
Compliant with IEC 61508 SIL3 safety standard, suitable for use in critical safety control systems.
Widely used in industrial safety systems such as petrochemicals, refineries, natural gas platforms, power and offshore platforms.
Used for emergency shutdown (ESD), process interlocking, critical equipment monitoring, and process optimization control.
TRICONEX 3700A分析模块 产品展示
