TRICONEX 8312电源模块 PDF资料
1.产 品 资 料 介 绍：
TRICONEX 8312 电源模块 产品特点
产品概述：
TRICONEX 8312 是 Tricon 安全控制系统（Tricon Safety System）中的核心电源模块，用于为主处理器模块、I/O 模块、分析模块及通信模块提供稳定可靠的直流电源，是整个 Triconex 系统稳定运行的基础保障。电源输出：
提供稳定 24 V DC 电压输出，用于驱动 Triconex 系统机架内的所有模块。
支持模块化供电，可为多个通道或模块提供独立电源分配。
三模冗余 (TMR) 支持：
电源模块设计与 Triconex TMR 架构兼容，可实现冗余供电配置。
在单个电源模块故障时，冗余模块可自动接管，保证系统不间断运行。
高可靠性设计：
工业级设计，具备抗电磁干扰、防震动、防尘、防潮湿能力。
提供过压、过流、短路保护，保障模块及系统安全。
诊断与监控功能：
内置电源状态指示灯及故障报警功能，实时显示模块工作状态。
可通过 Triconex 系统监控模块获取电源健康状态信息，便于运维。
安装与维护：
插入式模块化设计，便于现场安装与更换。
支持热插拔维护，减少系统停机时间。
应用领域：
石油化工、炼油厂、天然气平台及海上设施的安全仪表系统 (SIS)
电厂关键设备的安全控制与保护系统
各类工业自动化系统的安全关键控制模块供电
典型功能：
提供稳定、冗余的直流电源
支持整个 Triconex 系统模块供电
实现系统可靠性和连续性保障
TRICONEX 8312电源模块 英文介绍
TRICONEX 8312 power module product features
Product Overview:
The TriconeX 8312 is the core power module in the Tricon Safety System, used to provide stable and reliable DC power to the main processor module, I/O module, analysis module, and communication module. It is the fundamental guarantee for the stable operation of the entire Triconex system.
Power output:
Provide a stable 24V DC voltage output for driving all modules within the Triconex system rack.
Support modular power supply, which can provide independent power distribution for multiple channels or modules.
The third mock examination Redundancy (TMR) support:
The power module design is compatible with the Triconex TMR architecture and can achieve redundant power supply configuration.
When a single power module fails, redundant modules can automatically take over to ensure uninterrupted operation of the system.
High reliability design:
Industrial grade design, with the ability to resist electromagnetic interference, vibration, dust, and moisture.
Provide overvoltage, overcurrent, and short-circuit protection to ensure the safety of modules and systems.
Diagnostic and monitoring functions:
Built in power status indicator light and fault alarm function, real-time display of module working status.
The health status information of the power supply can be obtained through the Triconex system monitoring module for easy operation and maintenance.
Installation and maintenance:
Plug in modular design for easy on-site installation and replacement.
Support hot swappable maintenance to reduce system downtime.
Application fields:
Safety Instrumented Systems (SIS) for Petrochemical, Refinery, Natural Gas Platforms, and Offshore Facilities
Safety control and protection system for key equipment in power plants
Power supply for safety critical control modules of various industrial automation systems
Typical functions:
Provide stable and redundant DC power supply
Support power supply for the entire Triconex system module
Ensure system reliability and continuity
TRICONEX 8312电源模块 产品展示
