TRICONEX 3503E直流数字输入模块 PDF资料
1.产 品 资 料 介 绍：
TRICONEX 3503E 直流数字输入模块 产品特点
产品概述：
TRICONEX 3503E 是 Tricon 安全控制系统（Tricon Safety System）中的数字输入模块，用于采集现场直流信号并将其传输至主处理器模块，实现安全逻辑控制和过程监控。输入类型：
支持直流数字输入信号，通常为 24 V DC。
可采集开关量状态、接点闭合或断开信号。
多通道设计：
提供多路独立输入通道（典型为 16 或 32 通道，具体型号请参考技术数据表）。
每个通道独立隔离，防止通道间干扰，提高信号采集可靠性。
三模冗余 (TMR) 架构：
模块设计符合 Triconex TMR 标准，通过投票机制实现系统容错。
即使单通道或单模块出现故障，系统仍能保持正常运行，提高整体安全性。
诊断与自检功能：
内置通道状态监测与模块健康检查。
异常或故障时自动隔离故障通道并向主处理器报警。
模块化安装：
可插入 Triconex 系统机架，与主处理器模块、输出模块及分析模块无缝协作。
支持热插拔维护，减少系统停机时间。
工业环境适应性：
具备抗电磁干扰、防震动、防尘、防潮湿能力，可在复杂工业环境下稳定运行。
安全等级与应用：
符合 IEC 61508 SIL3 安全完整性标准，适用于紧急停机 (ESD) 系统、过程联锁及关键设备保护。
广泛应用于石油化工、天然气平台、炼油厂、电厂及海上平台等安全关键工业系统。
TRICONEX 3503E直流数字输入模块 英文介绍
TRICONEX 3503E DC Digital Input Module Product Features
Product Overview:
TRICONEX 3503E is a digital input module in the Tricon Safety System, used to collect on-site DC signals and transmit them to the main processor module for safety logic control and process monitoring.
Input type:
Supports DC digital input signals, typically 24V DC.
Can collect switch status, contact closure or disconnection signals.
Multi channel design:
Provide multiple independent input channels (typically 16 or 32 channels, please refer to the technical data sheet for specific models).
Each channel is independently isolated to prevent interference between channels and improve signal acquisition reliability.
The third mock examination Redundancy (TMR) architecture:
The module design complies with the Triconex TMR standard and achieves system fault tolerance through a voting mechanism.
Even if a single channel or module fails, the system can still maintain normal operation, improving overall safety.
Diagnostic and self checking functions:
Built in channel status monitoring and module health check.
Automatically isolate the faulty channel and alert the main processor in case of abnormality or malfunction.
Modular installation:
Can be inserted into the Triconex system rack, seamlessly collaborating with the main processor module, output module, and analysis module.
Support hot swappable maintenance to reduce system downtime.
Industrial environment adaptability:
It has the ability to resist electromagnetic interference, vibration, dust, and moisture, and can operate stably in complex industrial environments.
Security level and application:
Compliant with IEC 61508 SIL3 safety integrity standard, suitable for emergency shutdown (ESD) systems, process interlocks, and critical equipment protection.
Widely used in safety critical industrial systems such as petrochemicals, natural gas platforms, refineries, power plants, and offshore platforms.
TRICONEX 3503E直流数字输入模块 产品展示
