SANYO DENKI Q2AA07030DXS2交流伺服电机 PDF资料
1.产 品 资 料 介 绍：
一、产品定位与系列归属
属于 SANMOTION Q 系列 AC 伺服电机。
“Q2” 表示中惯量等级，适合在响应速度与负载惯量匹配之间取得平衡的场合。
型号 “Q2AA07030DXS2” 的后缀 “DXS2” 表示该电机在结构、版本或反馈方式上是某种特定变种（如高精度、特定轴长度或编码器版本）。
二、典型规格 （基于推断 + 可查信息）
以下为该型号电机在类似型号（如 Q2AA07030DXS25 / DXS26）基础上的合理参数估算与已知信息整合：
| 项目 | 估算 / 已知值 |
|---|---|
| 额定功率 | 0.3 kW（即 300 W，常见 “030” 表示 0.3 kW 级别） |
| 额定电压 | AC 200–230 V 级别 |
| 额定扭矩 | 约 1.0 至 1.5 N·m（根据功率与转速换算） |
| 峰值转矩 | ≈ 2–3 倍额定扭矩（依设计差异） |
| 最高转速 | 约 3000–4000 r/min（依版本不同） |
| 法兰 / 外形 | 小型法兰型，与其他 Q 系列小功率型号相似 |
| 制动器 | 一般 “DXS2” 型号无内置制动 |
| 反馈装置 | 内置高分辨率编码器（用于闭环位置 / 速度控制） |
| 冷却方式 | 自然风冷或周边散热片结构 |
| 结构保护 | 封闭式壳体、带密封设计以防尘、防油污染 |
三、产品特点与优势
小功率设计，结构紧凑
适用于对功率要求不高但对控制精度和响应速度有要求的中小型设备。中惯量结构，兼顾稳定与响应性
较低惯量便于响应变化，较高惯量有助于稳定性，适用于多种负载匹配情况。高精度控制与平稳输出
内部编码器和优化电磁设计使其具备较好的定位精度和低波动输出。兼容性与替换便利
与 Q 系列其他型号在结构和安装尺寸上可能具有较高兼容性，便于替换或改造。适应多数工业环境
密封结构有助于防尘、防油污染，提高可靠性。
SANYO DENKI Q2AA07030DXS2交流伺服电机 英文介绍
1、 Product positioning and series ownership
Belonging to the SANMOTION Q series AC servo motor.
Q2 "represents the intermediate inertia level, which is suitable for achieving a balance between response speed and load inertia matching.
The suffix "DXS2" of model "Q2AA07030DXS2" indicates that the motor is a specific variant in structure, version, or feedback mode (such as high precision, specific shaft length, or encoder version).
2、 Typical specifications (based on inference+traceable information)
The following is a reasonable parameter estimation and integration of known information for this model of motor based on similar models (such as Q2AA07030DXS25/DXS26):
Project estimation/known value
Rated power of 0.3 kW (i.e. 300 W, commonly referred to as "030" for 0.3 kW level)
Rated voltage AC 200-230 V level
Rated torque of approximately 1.0 to 1.5 N · m (converted based on power and speed)
Peak torque ≈ 2-3 times rated torque (depending on design differences)
The maximum speed is about 3000-4000 r/min (depending on the version)
Flange/Small shaped flange type, similar to other Q series low-power models
The general "DXS2" model of brakes does not have built-in brakes
Feedback device with built-in high-resolution encoder (for closed-loop position/velocity control)
Cooling method: natural air cooling or peripheral heat sink structure
Structural protection enclosed shell with sealed design to prevent dust and oil pollution
3、 Product features and advantages
Low power design, compact structure
Suitable for small and medium-sized equipment that do not require high power but have requirements for control accuracy and response speed.
Medium inertia structure, balancing stability and responsiveness
Lower inertia facilitates response to changes, while higher inertia contributes to stability and is suitable for various load matching situations.
High precision control and smooth output
The internal encoder and optimized electromagnetic design enable it to have good positioning accuracy and low fluctuation output.
Compatibility and easy replacement
It may have high compatibility with other models in the Q series in terms of structure and installation dimensions, making it easy to replace or modify.
Adapt to most industrial environments
The sealed structure helps prevent dust and oil pollution, and improves reliability.
SANYO DENKI Q2AA07030DXS2交流伺服电机 产品展示
