SANYO DENKI PY2A030A3-AL伺服驱动器 PDF资料
1.产 品 资 料 介 绍：
一、主要规格
输入电源：单相 AC 200–230 V，50/60 Hz
输入电流：约 10 A
输出（驱动电机端）：三相，输出电流约 5.2 A，输出电压 0–326 V，PWM 频率约 8 kHz
适配电机功率：约 1.5 kW
最大适用电机转速：约 4,500 rpm
电气 / 机械时间常数：电气约 13 ms，机械约 0.59 ms
二、产品特点
紧凑型设计
所属 PY2 系列，体积比传统型号小，节省安装空间。多模式控制
支持位置、速度、转矩控制模式，适合中功率伺服系统。调谐功能
包括离线/在线自动整定及滤波调谐，可优化电机性能。可靠散热
建议垂直安装并保持通风空间以控制温升。
三、使用建议与注意事项
驱动器需与电机额定功率、电流匹配，避免过载。
安装时保证输入电源稳定，且接地良好以防电气干扰。
需自行提供或确认电路保险丝以防过载。
布线应尽量减少高频 PWM 干扰，符合电磁兼容要求。
SANYO DENKI PY2A030A3-AL伺服驱动器 英文介绍
1、 Main specifications
Input power supply: single-phase AC 200-230 V, 50/60 Hz
Input current: approximately 10 A
Output (drive motor end): three-phase, output current of about 5.2 A, output voltage of 0-326 V, PWM frequency of about 8 kHz
Suitable motor power: approximately 1.5 kW
Maximum applicable motor speed: approximately 4500 rpm
Electrical/mechanical time constant: approximately 13 ms for electrical and 0.59 ms for mechanical
2、 Product Features
compact design
Belonging to the PY2 series, the volume is smaller than traditional models, saving installation space.
Multi mode control
Supports position, speed, and torque control modes, suitable for medium power servo systems.
Tuning function
Including offline/online automatic tuning and filtering tuning, it can optimize motor performance.
Reliable heat dissipation
It is recommended to install vertically and maintain a ventilated space to control temperature rise.
3、 Usage suggestions and precautions
The driver needs to match the rated power and current of the motor to avoid overload.
Ensure stable input power supply and good grounding during installation to prevent electrical interference.
You need to provide or confirm the circuit fuse yourself to prevent overload.
Wiring should minimize high-frequency PWM interference and comply with electromagnetic compatibility requirements.
SANYO DENKI PY2A030A3-AL伺服驱动器 产品展示
